Product: Akyapak ASM-S 200-30-5
ASM-S series asymmetric plate bending machines are robust and power, with a fully welded steel frame. The top and lower rolls are driven by an eletric motor, gearbox and gear system. This machine has a 3100mm maximum working length with 6mm material capac
NEW Akyapak ASM-S 200-30-5 Plate Rolling Machine.
Machine Specifications:
- 3100mm working length
- 5mm prebending capacity
- 6mm maximum thickness
- 200mm top roll diameter
- 300mm minimum bending diameter
- 5.5kW motor power
- 4800 x 1300 x 1270 machine size (L x W x H)
- 4800kg machine weight
ASM-S series asymmetric plate bending machines are robust and power, with a fully welded steel frame. The top and lower rolls are driven by an eletric motor, gearbox and gear system.
Standard features:
- Induction hardened rolls
- Motorised back roll
- Cone bending device
- Asymmetic working principle
- Top roll can be swiveled out
- Separate, movable control panel
- CE & ISO9001 production quality
