Product: Bossray SB-50CNC Bender
50.8 x 2.0mm bending capacity (carbon steel), 2600mm Max feeding length, CNC controlled.

Bossray SB-50CNC Tube bender

- Maximum Bending capacity 50.8mm x 2.0mm
 - Maximum feeding length 2600mm (custom sizes can be manufactured)
 - Maximum bending angle 190 degrees
 - Control Panel Mitsubishi Japan
 - Touch screen Wienview Taiwan
 - Accuracy +/- 0.1 degrees
 - Hydraulic motor 7.5kw
 - Machine weight 2,200kg
 - Machine size 4700mm x 1100mm x 1500mm

Features / Equipment:

  • Bending arm (C-axis) is hydraulic, Clamping is hydraulic.
  • Carriage (Y-axis) is by a servo motor, rotation is by a servo motor
  • Mandrel lubrication system.
  • Fan-cooling system
  • Foot pedal for a safe start.
  • Touch screen display
  • Can operate in manual, semi-automatic and fully automatic modes
  • Security code for the protection of data
  • CNC fully auto, have cubical space bending equipment, making the whole bending process is automatic.
  • CE, ISO9001 Certification.
