Product: Yawei PBH 80-2550 CNC5 (53T)
Hydraulically synchronised CNC pressbrake, 80 ton, 2550mm bed length, Delem DA-53T CNC control, 5 axis (Y1, Y2, X, R & CNC crowning), Rolleri tooling

New Machtech Yawei Synchro Pressbrake model PBH 80-2550 CNC5.

Features include:

80 ton bending force
2550mm bending length
2150mm between frames
350mm throat depth
175mm ram stroke
480mm open height
5 axis CNC (Y1, Y2, X, R & CNC hydraulic crowning compensation)
2 front sheet supports moving freely on linear guide


Controller:

Delem DA-52 CNC control
pendant mounted
equipped with Delem user-friendly interface including hotkey navigation
USB interface enables quick and easy memory stick backup of product and tool information
6.4" VGA colour TFT


Tooling:

Full set of Rolleri (Italian) top tooling in 835mm lengths
Full set of Rolleri (Italian) bottom tooling in 835mm lengths
Quick release clamps for fast, efficient tool changes
** A conventional wide table with full length multi-V die block available on request


Guards:

Lazersafe Light Guard System (Australia)
Physical rear and side guards with interlock


General:

Hoerbiger hydraulic system (Germany)
Heidenhain linear scales
Sumitomo oil pump
Deformation compensation on throat
precision ballscrew backgauge, AC servo motor driven and running on a linear guide.
7.5kW main motor power
230L oil tank
Weight: 6,800kg
Size: 3140 x 1540 x 2240mm


All Machtech Yawei Synchro PBH series pressbrakes maintain perfect control of the beam positioning at all times. This is achieved by fully closed loop electro-hydraulic servo control of Y1 & Y2. The beam position is measured by independent linear scales, attached to decoupled measuring frames.

These pressbrakes are of the highest quality and are perfectly suited to high production, high accuracy work environments.
